Diagram of the Electron Transport Chain

Electron Transport Chain &
Cellular Respiration
CLASS NOTES from Science Prof Online


All living things run on energy. If the organism is a plant or autotrophic microbe, the energy comes from sunlight. For all other forms of life, energy is extracted from nutrients through the reactions of metabolism--cellular respiration.

Cellular Respiration and the Electron Transport Chain (ETC)
Regardless of whether the original form of energy is sunlight or food, it must ultimately be converted to the cellular energy currency of adenosine triphosphate (ATP).
Article Summary: The electron transport chain is the most complex and productive pathway of cellular respiration. Here's a straightforward, simplified explanation of how the ETC works.
The Basics of the Electron Transport Chain
Virtual Microbiology

You have free access to a large collection of materials used in a college-level introductory microbiology course. The Virtual Microbiology Classroom provides a wide range of free educational resources including PowerPoint Lectures, Study Guides, Review Questions and Practice Test Questions.
Prokaryotic Cell, Mariana Ruiz
More Helpful Resources on Metabolism & Electron Transport
Electron Transport Chain of Cellular Respiration
facebook link
SPO twitter
Tamislinked in page
Illustration of Electron Transport Chain
3. Phosphorylation of ADP (The Payoff!)
The H+ on the side of the membrane in which they are most concentrated will eventually flow back across the membrane, down the electrochemical proton gradient through an enzyme called ATP synthase. As each H+ moves back across the membrane, ATP synthase phosphorylates adenosine diphosphate (ADP) to make the high energy molecule ATP, which can be used for many different energy-requiring reactions throughout the cell.
Electron Transport Chain: Black arrows represent electron transport. Red arrows represent hydrogen ions (H+).
Virtual Cell Biology

You have free access to a large collection of materials used in a college-level introductory Cell Biology Course. The Virtual Cell Biology Classroom provides a wide range of free educational resources including Power Point Lectures, Study Guides, Review Questions and Practice Test Questions.
Endomembrane System of a Eukaryotic Cell, Mariana Ruiz
See the
Electron Transport Chain Classroom Activity
for a fun, hands-on way to teach students the steps of the ETC!
​Page last updated

SPO is a FREE science education website. Donations are key in helping us provide this resource with fewer ads.
Please help!

(This donation link uses PayPal on a secure connection.)

For most organisms, this conversion is accomplished though cellular respiration, a series of pathways in which glucose (sugar) is broken down and the energy extracted is converted to ATP. The pathways of cellular respiration include glycolysis, conversion of acetyl-CoA, Kreb’s cycle and electron transport. Electron transport is the most complex and productive pathway of cellular respiration. During aerobic respiration, the ETC produces 34 of the 38 ATP molecules obtained from every molecule of glucose.

Where the Electron Transport Chain Is Located
Electron transport requires a membrane in order to work. In prokaryotic cells, those of bacteria and bacteria-like Archaeans, electron transport takes place in the cell’s plasma membrane. In eukaryotic cells, the more evolutionarily advanced and complex cells of animalsplants and fungi, electron transport takes place in cellular organelles known as mitochondria—the eukaryotic cell’s tiny power factories.

How Electron Transport Works
Most of the ATP made in cellular respiration comes from the stepwise release of energy, through a series of oxidation-reduction (redox) reactions between molecules embedded in the plasma membrane (prokaryotes) or mitochondria (eukaryotes).

It is easiest to understand how electron transport works to divide it into three main events:

1. Oxidation Reduction Reactions
During glycolysis, synthesis of acetyl-CoA and Kreb’s cycles the electron carriers NAD+ and FADH are reduced to form NADH and FADH2 respectively. These molecules are like little rechargeable batteries, and when NAD+ and FADH are reduced, this means that they accept and carry electrons and hydrogen ions (H+) potential energy that can be used later in cellular respiration.

In the electron transport chain, these electron carriers are oxidized, transferring their electrons to the carrier molecules embedded in the ETC membrane. The electrons are then passed from one carrier molecule to another in a series of oxidation-reduction reactions, and finally, in aerobic respiration, to the final electron acceptor, oxygen (O2).

2. Creation of Hydrogen Ion Gradient
The energy from each electron being passed down the chain is used to pump a proton (H+) through each carrier molecule, from one side of the membrane to the other. This creates a proton gradient, a type of concentration gradient (difference in concentration of a substance between two sides of a membrane), and gradients are potential energy available for cellular work.
